| Range |
1T to 10T |
| Compact & Light weight |
Designed for portability and ease of handling. |
| All major Forging, Casting, Gears components and Chains produced in-house |
Assured quality and reliability. |
| Spur Alloy steel gears with case hardening |
Precision cut spur gears ensure smooth and efficient operation with minimal effort. |
| Fully pocketed S. G. Iron casting load chain wheel mounted on double ball bearing |
Ensures accurate and smooth operation. |
| Alloy Steel Load Chain |
Provides added strength, wear resistance, longer chain life. |
| Plated Hand Chain |
Offers better aesthetic looks, increased rust protection and longer chain life. |
| Hand chain wheel cover |
Minimizes jamming & slipping. |
| Brakes |
Mechanical screw friction self-actuating disc load brake engages instantly for load holding. Two Ratchet Pawls for extra safety. |
| Load and suspension hook with Safety Latches |
Prevents unintentional unhooking of the load. |
| Machined Guide rollers |
Ensure smooth running of load chain. |
| Powder Coated finish |
For added rust protection and better aesthetics. |
| Easy to maintain |
Chain block can be easily dismantled for maintenance with simple tools available in the workshop. |
| Over Load Test |
Chain block tested for 150% of SWL as per IS 3832. |
