| Aluminium Die Cast Body |
Compact, tough body. |
| Alloy steel gears |
Precision cut spur gears ensure smooth and efficient operation with reduced noise. |
| Grade 80 load chain |
Provides added strength, wear resistance, longer chain life. |
| Hooks |
Forged hook, free swiveling with safety latch. Bottom hook with thrust bearing. |
| Wrong Phase Protector |
Wrong Phase Protector protects the motor in case of wrong phase position. |
| Limit Switches |
Stop hoist at both ends of the hook path. |
| Motor |
Squirrel cage induction motor with 40% CDF and IP-55 protection. |
| Panel |
Built-in panel with IP-55 protection. |
| Control Pendant Button |
Durable, waterproof, lightweight with IP-55 protection. For extra safety emergency stop button provided. |
| Powder Coated finish |
For added rust protection and better aesthetics. |
| Interchangeability of Parts |
Reduces inventory. |
